Pressure Transmitter
Cod. PRE-115
Cod. PRE-115
Accurate to ±1% of full scale, The Series 628CR Pressure Transmitter, contains a low cost ceramic sensor housed in a compact, rugged, NEMA 4X stainless steel body. Ideal for the budget conscious OEM's that require high levels of performance, reliability and stability at an unbeatable price. The 628CR housing is small and lightweight for optimum compatibility with OEM systems. The design allows for a variety of pressure ranges from -14.7 to 500 psi and optional electrical connections allowing you to select the right transmitter for your application.
Service
Compatible gases and liquids
Wetted Materials
Ceramic, fluoroelastomer, 316L SS.
Accuracy
±1.0% FS (includes linearity, hysteresis and repeatability)
Stability
±0.25% FS/year
Temperature Limits
0 to 185°F (-18 to 85°C)
Compensated Temperature Range
0 to 175°F (-18 to 79°C)
Pressure Limit
Max. Pressure: 2x range; Burst Pressure: 3x range
Thermal Effect
±0.04% FS/°F
Power Requirements
9 to 30 VDC
Output Signal: 4 to 20 mA
4 to 20 mA
Response Time
3 ms typ
Loop Resistance
0-1200 Ohm max
Current Consumption
40 mA max
Electrical Connections
Cable or DIN connector
Process Connection
1/4" male NPT or 1/4" male BSPT
Enclosure Rating: NEMA 4X (IP65)
NEMA 4X (IP65)
Mounting Orientation
Mount in any position
Weight
4.0 oz
Agency Approvals
CE
Specifications
